R Packages: vignettes + dissemination

Grayson White

Math 241
Week 12 | Spring 2026

Week’s Goals

Mon Lecture

R package documentation and metadata

Wed Lecture

R package testing
R package dissemination:
- Vignettes, and
- package websites

Recap Ou`R` Package: `pdxHoles`

Share the Portland reported potholes dataset, along with documentation.
Includes, plot_holes(), a function that plots the location of the potholes along with their status.
Working copy can be found at https://github.com/Reed-Data-Science/pdxHoles

Other questions so far?

Testing

Testing – Informally

Return to our first function:

coef_of_var <- function(x, na.rm = FALSE, trim = 0){
  stopifnot(is.numeric(x))
  sd(x, na.rm = na.rm) / mean(x, na.rm = na.rm, trim = trim)
}

Ran so many tests!

coef_of_var(x = rnorm(n = 10000, mean = 1, sd = 4))

[1] 3.931291

Testing – Informally

Ran so many tests!

library(pdxTrees)
pdxTrees <- get_pdxTrees_parks()
DBH_new <- c(pdxTrees$DBH, Inf)
coef_of_var(DBH_new)

[1] NaN

coef_of_var(pdxTrees)

Error in `coef_of_var()`:
! is.numeric(x) is not TRUE

Testing – Informally

Ran so many tests!

coef_of_var(pdxTrees$Condition)

Error in `coef_of_var()`:
! is.numeric(x) is not TRUE

coef_of_var(c(TRUE, FALSE, FALSE))

Error in `coef_of_var()`:
! is.numeric(x) is not TRUE

How should we formally test our package functions?

Testing our Package Functions

Standard workflow in package development:

Write/revise the function in an .R script.
- (Also write documentation using roxygen2)
Load the function with devtools::load_all()
Experiment with the function, giving it different inputs.
Repeat.

Step 3 likely involves similar informal testing as we were doing for our functions outside an R package.
Good to transition to automated testing (also called unit testing) using testthat!

Why Automated Testing?

Fewer bugs.
- Describe the behavior of your function in both the code and the test. Check against each other.
- When adding a new feature to a function, you reduce the chances it breaks the existing features.
Can help motivate more refactoring of your code.
- Functions that are easier to test are usually easier to understand.

`testthat`

Within your package RStudio Project, run the following to get started:

usethis::use_testthat()

Modifies your DESCRIPTION file:

Suggests: testthat (>= 3.0.0)
Config/testthat/edition: 3

Creates the tests/testthat folder.
In particular, we now have a testthat.R file that will initiate all your tests every time you run devtools::check().

Test File Structure

For every insert_function_name.R function in the R folder that you want tests for, create an test-insert_function_name.R for storing your tests.
- You can automate this process with:

usethis::use_test("plot_holes")

Each test file holds one or more test_that() tests for a particular function in your package.

Each test:
- Describes what it is testing.
- Has one or more expectations.

Test File Structure

library(testthat)
test_that("multiplication works", {
  expect_equal(2 * 2, 4)
})

Test passed 😀

test_that("multiplication works", {
  expect_equal(2 * 2, 5)
})

── Failure: multiplication works ───────────────────────────────────────────────
2 * 2 not equal to 5.
1/1 mismatches
[1] 4 - 5 == -1

Error:
! Test failed

Expectations

Expectation: Expected result of a computation

Start with expect_---()
Two main arguments:
- 1st: Actual result
- 2nd: What you expect

expect_equal(2 * 2, 4)

expect_equal(2 * 2, 5)

Error:
! 2 * 2 not equal to 5.
1/1 mismatches
[1] 4 - 5 == -1

They automate the visual checking of results in the console.

Expectations

Expectation: Expected result of a computation

Key Questions:

Does it have the correct value(s) or dimensions?
Does it have the correct class?
Does it produce an error when it should?

Let’s explore some of the `expect_*()` functions in `testthat`!

Testing Equality

expect_equal(2 * 2, 4)
expect_equal(2 * 2, 4 + 0.0000001)

Error:
! 2 * 2 not equal to 4 + 1e-07.
1/1 mismatches
[1] 4 - 4 == -1e-07

expect_equal(2 * 2, 4 + 0.00000001)
expect_identical(2 * 2, 4 + 0.0000001)

Error:
! 2 * 2 not identical to 4 + 1e-07.
1/1 mismatches
[1] 4 - 4 == -1e-07

expect_equal(2 * 2, 4L)
expect_identical(2 * 2, 4L)

Error:
! 2 * 2 not identical to 4L.
Objects equal but not identical

Testing Class

Check the class of your output:

library(pdxHoles)
test_that("check class", {
  expect_s3_class(plot_holes(), "data.frame")
})

── Failure: check class ────────────────────────────────────────────────────────
plot_holes() inherits from 'ggplot2::ggplot'/'ggplot'/'ggplot2::gg'/'S7_object'/'gg' not 'data.frame'.

Error:
! Test failed

test_that("check class", {
  expect_s3_class(plot_holes(), "ggplot")
})

Test passed 😀

Testing Errors

Remember to use defensive coding in your function and then check them with your tests.

test_that("errors when it should", {
  expect_error(plot_holes(colors = c("green", "red")))
})

── Failure: errors when it should ──────────────────────────────────────────────
`plot_holes(colors = c("green", "red"))` did not throw an error.

Error:
! Test failed

Need to put better checks in plot_holes().
There are similar functions for warnings and messages: expect_warning(), expect_message()

Testing Guidelines

Focus on outputs and behaviors of your functions.
- The defensive code in your functions focuses on the inputs.
Test each behavior in one test.
If you find a bug, write a test!

Running Tests – Three Options

Option 1: Refine a specific test

# Load the function
devtools::load_all()

# Write the body test
expect_equal(2 * 2, 4)

# Run the test
test_that("multiplication works", {
  expect_equal(2 * 2, 4)
})

Running Tests – Three Options

Option 2: Run all tests on a function

testthat::test_file("tests/testthat/test-plot_holes.R")

Option 3: Run all tests on all functions

devtools::test()
# OR
devtools::check()

Will error out if any of the tests don’t pass.

Vignettes

“The vignette format is perfect for showing a workflow that solves that particular problem, start to finish. Vignettes afford you different opportunities than help topics: you have much more control over the integration of code and prose and it’s a better setting for showing how multiple functions work together.” – Hadley Wickham and Jenny Bryan

browseVignettes()

Vignettes Set-up

To get started, run:

usethis::use_vignette("pdxHoles")

Which

Creates the vignettes folder.
Updates the DESCRIPTION with new dependencies.
Provides a template in the file pdxHoles.Rmd.
Updates your .gitignore.

Vignettes Workflow

Run devtools::load_all() to make sure you have access to the data and functions in the package.
Edit the narrative and code chunks.

To render the vignette using a temporarily installed, development version of your package, run

devtools::build_rmd("vignettes/pdxHoles.Rmd")

Inspect the output file.
Repeat!

Vignettes Workflow

Eventually,

To make the current state available locally with an install of the package:

devtools::install(dependencies = TRUE, build_vignettes = TRUE)

To get vignettes when installing a package from GitHub:

devtools::install_github(dependencies = TRUE, build_vignettes = TRUE)

Vignettes are always built when you submit to CRAN:

devtools::submit_cran()

Suggestions for Writing a Good Vignette

Think of your vignette as an instructive tutorial.
First, identify (for yourself) what you want the vignette to accomplish.
Be careful with the curse of knowledge.
Break up the code with concise but clear narrative that motivates the next block of code.
Hyper-link to other relevant packages and functions.

Important Note:

Any package used in a vignette must be listed in the DESCRIPTION file under either Imports or Suggests.

Website for Your Package with `pkgdown`

Create the Site

Run:

usethis::use_pkgdown()

Creates pkgdown.yml: The configuration file for your package.
Adds the correct files to the .Rbuildignore.
Creates the docs folder which will store all the pages for the website.

Build the Site

To create the site, run:

pkgdown::build_site()

The site is only as good as the documentation included in your package.
- But, if you have created useful help files, an informative Readme, a complete DESCRIPTION file, and a vignette, then your default pkgdown site will be pretty great!

Deploy the Site

To set it up so that your site can be published to a GitHub pages, run (just once):

usethis::use_pkgdown_github_pages()

Creates a branch in GitHub that will store the files for your website.
Turns on GitHub Pages for your repo
- Let’s GitHub know where to find the files for the website.
Adds the URL for the site to the appropriate files.

Deploy the Site

Big Wrinkle: Can’t deploy on our private GitHub Organization.

Have to deploy through a repo tied to your individual account
Requires changing a GitHub Action setting!
Not a requirement of Project 2!

Hex Sticker

A strong tradition in the R community.
Fun way to remember and advertise a package.

Hex Sticker

A strong tradition in the R community.
Fun way to remember and advertise a package.

Hex Sticker

A strong tradition in the R community.
Fun way to remember and advertise a package.

But there are rules…

Next week

The final week of classes… 😿
Some project work time (Monday)
Building your data science profile (Wednesday)
